Geberit Delta 21 Concealed Dual Flush Toilet Cistern WC 12cm 570 x 445mm

Geberit 109.103.21.1 Delta 50 Concealed Toilet Cistern 12cm
For drywall construction
For installation in part- or room-height prewall installations
For installation in room-height installation walls
For floor-standing WCs

Characteristics
Concealed cistern with front actuation
Concealed cistern fully insulated against condensation
Cistern fulfils standard requirements in accordance with EN 14055, Class II
Immediate post flush possible with factory setting
Flush bend fitted
Water supply connection on the rear or top centre
Connection hose on angle stop valve can be attached without tools

Specifications of the Geberit 109.103.21.1 Delta 50 Concealed Toilet Cistern 12cm

Flow pressure 0.1 10 bar
Maximum operating temperature, water 25 C
Flush volume, factory setting 5.8 and 3 l
Flush volume small, adjustment range 3 4 l
Angle stop valve R 1/2", compatible with MeplaFix, with adaptor ring
Protection box for service opening, made of polystyrene foam
Flush plate Delta21
2 distance bolts
Flush bend 90
Protection plug
Fastening for flush bend
2 fixing brackets
Fastening material
